Tescan Spectral CT in Electronics and Semiconductors

Non-destructive spectral imaging for material verification and internal inspection of advanced electronic assemblies.

TrueContrast™ multi-energy imaging for differentiating polymers, metals, and encapsulants

K-edge detection for accurate identification of high-Z elements
Non-destructive visualization of interfaces and buried defects in electronic packages
Spectrum comparison tools for verifying material uniformity and contamination sources

Tescan Spectral CT delivers compositional insight where conventional micro-CT cannot. Engineers can distinguish packaging materials, solder alloys, and internal structures without sectioning or coating—supporting reliable failure analysis, design validation, and quality assurance across next-generation electronic devices.

Tescan Spectral CT in Materials Science

Multi-energy micro-CT for elemental and structural differentiation in complex, multi-phase materials.

Elemental mapping for identifying fillers, dopants, or additives in polymer composites
Spectral contrast for distinguishing polymers, ceramics, and metals with similar densities
Non-destructive 3D analysis of internal interfaces and phase boundaries
Integrated Spectral Suite for correlating elemental and structural data in one workflow

In materials research, Spectral CT enables scientists to explore the relationship between structure and composition without destroying samples. Researchers can visualize distribution of additives, analyze composite uniformity, and study degradation pathways—supporting more reliable material design and performance assessment.

Tescan Spectral CT in Geoscience and Mining

Full-spectrum micro-CT for 3D elemental and structural insight into geological samples.

Non-destructive 3D elemental mapping of rocks, ores, and mineral inclusions
K-edge detection for locating and identifying high-value or trace elements like gold or rare earth elements
Enhanced contrast for complex mineral assemblages and pore networks
Large-volume spectral scanning for full-core or fragment-scale analysis

For geoscientists and mining professionals, Spectral CT provides simultaneous elemental and structural data from intact samples. It supports mineral identification, ore classification, and recovery assessment—reducing dependency on destructive assays while preserving geological material for further study.

TESCAN SPECTRAL SUITE

INTEGRATION THAT DRIVES INSIGHT

Tescan Spectral CT works seamlessly with SPECTRAL Suite and Acquila™ micro-CT control software to streamline spectral imaging from acquisition to analysis. Used as an add-on with the UniTOM XL platform, users can target volumes of interest, capture full-spectrum data, and visualize structural and elemental information in one workflow.

Researchers benefit from intuitive controls, guided reconstruction, and automated spectral processing. Spectral Suite handles spectrum matching, K-edge detection, and compositional mapping with minimal setup. This delivers consistent, reproducible results across samples and accelerates multi-energy micro-CT analysis.

UniTOM® HR 2

Technical specification

X-ray source
	Source type	Open type transmission source
	Voltage	30-160kV
	Power	Up to 50W
X-ray detectors
X-ray detectors	Detector	High-speed, medium field of view with multiple detector options (up to three)
Resolution
	Spatial resolution	500 nm (2D line pair resolution)
	Temporal resolution	<5 seconds
Sample size and weight
	Maximum sample size (H x Ø)	700 mm x 500 mm
	Weight	45 kg
	Maximum imaging envelope (H x Ø)	400 mm x 300 mm
System weight and dimensions
	Installed (L x W x H)	2.06 m x 0.97 m x 1.9 m
	Installed weight	2750 kg
Rotation stage
Rotation stage	Stage	Continuous rotation with slip-ring technology for uninterrupted dynamic imaging
Software and In Situ connectivity
	Imaging modes	Continuous Dynamic CT, standard static CT, tiling, offset, stacked and merged integrated acquisition (STAMINA), multi-scale Volume of Interest Scanning (VOIS)
	In situ interface	Optional connection panel for in situ testing stages and environmental experiments with radiation-safe feedthroughs
		Integrated workflow control and data reconstruction through Acquila™ and Panthera™ software

X-ray source
Source type	Open type transmission source
Voltage	30-160kV
Power	Up to 50W
X-ray detectors
Detector	High-speed, medium field of view with multiple detector options (up to three)
Resolution
Spatial resolution	500 nm (2D line pair resolution)
Temporal resolution	<5 seconds
Sample size and weight
Maximum sample size (H x Ø)	700 mm x 500 mm
Weight	45 kg
Maximum imaging envelope (H x Ø)	400 mm x 300 mm
System weight and dimensions
Installed (L x W x H)	2.06 m x 0.97 m x 1.9 m
Installed weight	2750 kg
Rotation stage
Stage	Continuous rotation with slip-ring technology for uninterrupted dynamic imaging
Software and In Situ connectivity
Imaging modes	Continuous Dynamic CT, standard static CT, tiling, offset, stacked and merged integrated acquisition (STAMINA), multi-scale Volume of Interest Scanning (VOIS)
In situ interface	Optional connection panel for in situ testing stages and environmental experiments with radiation-safe feedthroughs
	Integrated workflow control and data reconstruction through Acquila™ and Panthera™ software
